Horizontal 4‑Axis

Reliability, stability and precision deliver peak performance and efficiency for every user.
a51nx sil

Take Control of Production with Speed, Accuracy and Reliability

Makino reliability and easy maintenance mean your machine maintains accuracy and productivity for years, adding value and ROI far beyond any other machine on the market.

Makino leverages the latest technology in every machine. Patented technologies in our high-speed, high-performance spindles give our machines the highest repeatable metal-removal rates. That’s why Makino users lead the industry in the speed and part quality customers demand.

Makino’s a1-Series machines are the top-selling 4-axis horizontals in Europe, setting the industry standard.

Contact Us

Pallet:

500 mm

19.7"

X:

730 mm

28.7"

Y:

750 mm

29.5"

Z:

500 mm - 700 mm

19.7" - 27.6"

Rapid Traverse:

60,000 mm/min

2,362 ipm

Maximum Workpiece:

Ø 630 mm x 500 mm High

Ø 24.9” x 19.7” High

Spindle Taper:

HSK-A63 / BT40


X:

560 mm

Y:

640 mm

Z:

640 mm

Rapid Traverse:

60,000 mm/min

Spindle Taper:

HSK-A63


1-Series (400 mm)

Pallet:

400 x 400 mm

15.75"

X:

560 mm

22.0"

Y:

640 mm

25.2"

Z:

640 mm

25.2"

Rapid Traverse:

60,000 mm/min

2,362 ipm

Maximum Workpiece:

ø630 mm x 900 mm

ø24.8" x 35.4"

Spindle Taper:

HSK-A63 / BT40

CAT40 (HSK-A63 opt)


Pallet:

400 x 400 mm

15.7" x 15.7"

X:

560 mm

22.0"

Y:

640 mm

25.2"

Z:

640 mm

25.2"

Rapid Traverse:

60,000 mm/min

2,362 ipm

Maximum Workpiece:

ø630 mm x 900 mm

ø24.8" x 35.4"

Spindle Taper:

HSK-A63 / BT40

40 (HSK63)


1-Series (500 mm)

Pallet:

500 x 500 mm

19.7" x 19.7"

X:

730 mm

28.7"

Y:

650 mm std (730 mm opt)

25.6" std (28.7" opt)

Z:

800 mm

31.5"

Rapid Traverse:

60,000 mm/min

2,362ipm

Maximum Workpiece:

ø800 mm x 1,000 mm

ø31.5" x 39.4"

Spindle Taper:

HSK-A63 / BT40

CAT40 (HSK-A63 opt)


Pallet:

500 x 500 mm

19.7" x 19.7"

X:

800 mm

31.5"

Y:

750 mm

29.5"

Z:

830 mm

32.7"

Rapid Traverse:

(X / Y) 50,000 mm/min, (Z) 60,000 mm/min

(X / Y) 1,968 IPM, (Z) 2,362 IPM

Maximum Workpiece:

ø900 mm x 1,000 mm

Spindle Taper:

HSK-A100 / BT50

CAT50 (HSK-A100 opt)


1-Series (630 mm)

Pallet:

630 mm

24.8"

X:

900 mm

35.4"

Y:

900 mm

35.4"

Z:

1,020 mm

40.2"

Rapid Traverse:

50,000 mm/min (Std), 36,000 mm/min (High Torque)

1,968 in/min (Std), 1,417 in/min (High Torque)

Maximum Workpiece:

ø1,000 mm x 1,300 mm

39.4" ø x 51.2"

Spindle Taper:

HSK-A100 / BT50

CAT50 (HSK-A100 opt)


1-Series (800 mm)

Pallet:

800 x 1,000 mm

31.5" x 39.4"

X:

1,520 mm

59.8"

Y:

1,250 mm

49.2"

Z:

1,350 mm

53.1"

Rapid Traverse:

50,000 mm/min

1,969 ipm

Maximum Workpiece:

ø1,500 x 1,500 mm

ø59" x 59"

Spindle Taper:

HSK-A100 / BT50

CAT50 (HSK-A100 opt)


1-Series (1000mm)

Pallet:

1,000 mm x 1,000 mm (Optional 1,250 x 1,000 mm)

39.4" x 39.4" (Optional 49.2" x 39.4")

X:

1,900 mm

74.8"

Y:

1.600 mm

63.0"

Z:

1,700 mm

66.9"

Rapid Traverse:

54,000 mm/min

2,126 IPM

Maximum Workpiece:

ø2,100mm x 1,800mm

ᴓ82.7" x 70.9"

Spindle Taper:

CAT50 (HSK-A100 opt)


J-Series

Pallet:

ᴓ400 mm std. (400 x 400 mm opt.)

15.7"

X:

400 mm std (630 mm opt.)

15.7" (24.8" opt.)

Y:

400 mm std (550 mm opt.)

15.7" (21.7" opt.)

Z:

400 mm std (550 mm opt.)

15.7" (21.7" opt.)

Rapid Traverse:

65,000 mm/min

2,362 in/min

Maximum Workpiece:

Up to ᴓ710 mm X 580 mm (with limitations)

ᴓ27.9" X 28.7" (consult factory)

Spindle Taper:

HSK-A50 (HSK-A63 opt)

HSK-A50 (HSK-A63 opt)
